Hei, en god dag til dere.
Har en Kuga 2014 modell. Diesel automat.
To ganger har bilen fått opp en "haug" med feilkoder, gir melding(er) om at ting ikke funker og motoren stopper.
Tror ikke jeg har feilkoder ved akkurat de stoppene, men har to bulker med feil som jeg har fått kopiert ut.
Stoppet den 10/1 var en uke på et verksted før de transporterte den til merkeverksted hvor den har vært siden.
De feilsøker visst fortsatt. (Ringte etter 5 dager for å høre om de fortsatt skulle feilsøke da "kronasjen" kunne øke kraftig.)
Legger ved de to feil filene jeg har.
Mvh
Ole Johnny
Mener denne datert 22/1-22
*******************************************
Car Scanner ELM OBD2
DTC report
Selected brand: Ford
VIN: WF0AXXWPMAEU79470
============1==============
U0104(00)
Raw code: C10400
ECU: Engine control unit[Archive (inactive)]
Status: Confirmed, Test failed since last DTC clear
OBDII: Data bus, cruise control module - no communication
============2==============
P188C(00)
Raw code: 188C00
ECU: Engine control unit[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: ALL WHEEL DRIVE RELAY MODULE COMMUNICATION CIRCUIT
============3==============
P068A(00)
Raw code: 068A00
ECU: Engine control unit[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Engine control (EC) relay - shut-off early
============4==============
P1139(01)
Raw code: 113901
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Water In Fuel Indicator Circuit Malfunction
Ford: Water In Fuel Indicator Circuit Malfunction
============5==============
P1140(00)
Raw code: 114000
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Water In Fuel Condition
Ford: Water In Fuel Condition
============6==============
P003A(91)
Raw code: 003A91
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Turbocharger (TC)/supercharger (SC) boost pressure control A - learning limit exceeded
============7==============
P003A(85)
Raw code: 003A85
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Turbocharger (TC)/supercharger (SC) boost pressure control A - learning limit exceeded
============8==============
U2101(00)
Raw code: E10100
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: CAN data bus - ECM incorrectly programmed
============9==============
P0094(00)
Raw code: 009400
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Fuel system leak - small leak detected
============10==============
P0093(00)
Raw code: 009300
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Fuel system leak - large leak detected
============11==============
P169F(00)
Raw code: 169F00
ECU: Engine control unit
Status: Test not completed during this operation cycle
============12==============
P1531(96)
Raw code: 153196
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid Test - Accelerator Pedal Movement
Ford: Invalid Test - Accelerator Pedal Movement
============13==============
P0219(00)
Raw code: 021900
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Engine over speed condition
Ford: Engine Overspeed Condition
============14==============
P0266(92)
Raw code: 026692
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Cylinder 2 - contribution/balance fault
Ford: Cylinder #2 Balance Fault
============15==============
P0272(92)
Raw code: 027292
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Cylinder 4 - contribution/balance fault
Ford: Cylinder #4 Balance Fault
============16==============
P0269(92)
Raw code: 026992
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Cylinder 3 - contribution/balance fault
Ford: Cylinder #3 Balance Fault
============17==============
P0263(92)
Raw code: 026392
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Cylinder 1 - contribution/balance fault
Ford: Cylinder #1 Balance Fault
============18==============
P1774(02)
Raw code: 177402
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
============19==============
P1643(64)
Raw code: 164364
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Fuel Pump Monitor Circuit Low Input
Ford: Fuel Pump Monitor Circuit Low Input
============20==============
P1774(64)
Raw code: 177464
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
============21==============
U0404(64)
Raw code: C40464
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid data received - gear shift module
============22==============
P061C(64)
Raw code: 061C64
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Engine control module (ECM), engine rpm - performance problem
============23==============
P1304(00)
Raw code: 130400
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: EGR Calibration High
Ford: EGR Calibration High
============24==============
P1304(91)
Raw code: 130491
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: EGR Calibration High
Ford: EGR Calibration High
============25==============
P1304(85)
Raw code: 130485
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: EGR Calibration High
Ford: EGR Calibration High
============26==============
P1936(31)
Raw code: 193631
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
============27==============
P164D(00)
Raw code: 164D00
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
Ford: ALL WHEEL DRIVE ID BLOCK CORRUPTED, NOT PROGRAMMED
============28==============
U0418(00)
Raw code: C41800
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid data received - brake system control module
============29==============
U0426(00)
Raw code: C42600
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid data received - immobilizer control module
============30==============
P188C(00)
Raw code: 188C00
ECU: Engine control unit[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: ALL WHEEL DRIVE RELAY MODULE COMMUNICATION CIRCUIT
============31==============
U0104(00)
Raw code: C10400
ECU: Engine control unit[Archive (inactive)]
Status: Confirmed, Test failed since last DTC clear
OBDII: Data bus, cruise control module - no communication
============32==============
P068A(00)
Raw code: 068A00
ECU: Engine control unit[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Engine control (EC) relay - shut-off early
============33==============
U0126(00)
Raw code: C12600
ECU: ABS/ESP[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Data bus, steering position sensor control module - no communication
============34==============
U0401(00)
Raw code: C40100
ECU: ABS/ESP[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Invalid data received - engine control module (ECM)
============35==============
U0104(00)
Raw code: C10400
ECU: ABS/ESP[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Data bus, cruise control module - no communication
============36==============
U3003(16)
Raw code: F00316
ECU: ABS/ESP[Archive (inactive)]
Status: Confirmed, Test failed since last DTC clear, Test not completed during this operation cycle
OBDII: Battery voltage
============37==============
U0437(68)
Raw code: C43768
ECU: ABS/ESP[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Invalid data received from differential control module, rear
============38==============
U0257(00)
Raw code: C25700
ECU: APIM
Status: Test failed, Test failed (current drive cycle), Confirmed
OBDII: Lost communication with front controls/display interface module
============39==============
U3003(16)
Raw code: F00316
ECU: APIM[Archive (inactive)]
Status: Confirmed
OBDII: Battery voltage
============40==============
B1D38(16)
Raw code: 9D3816
ECU: BCM[Archive (inactive)]
Status: Confirmed, Test failed since last DTC clear
============41==============
B1D38(19)
Raw code: 9D3819
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
============42==============
B1088(86)
Raw code: 908886
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
============43==============
U3003(16)
Raw code: F00316
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Battery voltage
============44==============
U3008(13)
Raw code: F00813
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Control module - earth connection A
============45==============
B12BD(83)
Raw code: 92BD83
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
============46==============
U0264(87)
Raw code: C26487
ECU: BCM
Status: Test failed, Test failed (current drive cycle), Pending, Confirmed, Test failed since last DTC clear
OBDII: Lost communication with camera module
============47==============
B1390(87)
Raw code: 939087
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
Ford: Oil Temperature Sensor Circuit Short To Ground
============48==============
B1287(15)
Raw code: 928715
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
Ford: Servo Motor Potentiometer Airintake Left Circuit Short To Ground
============49==============
B1D13(11)
Raw code: 9D1311
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
============50==============
B109B(15)
Raw code: 909B15
ECU: BCM
Status: Test failed, Test failed (current drive cycle), Pending, Confirmed, Test failed since last DTC clear
============51==============
B1133(11)
Raw code: 913311
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear, Test not completed during this operation cycle
============52==============
U0104(00)
Raw code: C10400
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Data bus, cruise control module - no communication
============53==============
U0405(81)
Raw code: C40581
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Invalid data received - cruise control module
============54==============
U2001(87)
Raw code: E00187
ECU: BCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Audio Tape Deck Unit is Not Responding
Ford: Audio Tape Deck Unit is Not Responding
============55==============
B1A57(87)
Raw code: 9A5787
ECU: HCM[Archive (inactive)]
Status: Test failed since last DTC clear, Test not completed during this operation cycle
============56==============
B1A58(87)
Raw code: 9A5887
ECU: HCM[Archive (inactive)]
Status: Test failed since last DTC clear, Test not completed during this operation cycle
============57==============
B1A59(11)
Raw code: 9A5911
ECU: HCM[Archive (inactive)]
Status: Test failed since last DTC clear, Test not completed during this operation cycle
============58==============
B1C98(13)
Raw code: 9C9813
ECU: HCM[Archive (inactive)]
Status: Test failed since last DTC clear, Test not completed during this operation cycle
============59==============
B1C99(13)
Raw code: 9C9913
ECU: HCM[Archive (inactive)]
Status: Test failed since last DTC clear
============60==============
U0001(88)
Raw code: C00188
ECU: HCM
Status: Pending, Confirmed, Test failed since last DTC clear, Test not completed during this operation cycle
OBDII: Controller area network (CAN) data bus, high speed bus
============61==============
U3003(16)
Raw code: F00316
ECU: HCM[Archive (inactive)]
Status: Test failed since last DTC clear, Test not completed during this operation cycle
OBDII: Battery voltage
============62==============
U3003(13)
Raw code: F00313
ECU: PSCM[Archive (inactive)]
Status: Confirmed
OBDII: Battery voltage
============63==============
U0140(00)
Raw code: C14000
ECU: RCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Data bus, body control module (BCM) - no communication
============64==============
U0253(00)
Raw code: C25300
ECU: RCM[Archive (inactive)]
Status: Confirmed, Test failed since last DTC clear
OBDII: Lost communication with accessory protocol interface module
============65==============
U2300(64)
Raw code: E30064
ECU: RCM[Archive (inactive)]
Status: Confirmed, Test failed since last DTC clear
============66==============
U3003(16)
Raw code: F00316
ECU: RCM[Archive (inactive)]
Status: Test failed since last DTC clear
OBDII: Battery voltage
***********************
Denne fra 31/12-22
Car Scanner ELM OBD2
DTC report
Selected brand: Ford
VIN: WF0AXXWPMAEU79470
============1==============
P1139(01)
Raw code: 113901
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Water In Fuel Indicator Circuit Malfunction
Ford: Water In Fuel Indicator Circuit Malfunction
============2==============
P1140(00)
Raw code: 114000
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Water In Fuel Condition
Ford: Water In Fuel Condition
============3==============
U2101(00)
Raw code: E10100
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: CAN data bus - ECM incorrectly programmed
============4==============
P0094(00)
Raw code: 009400
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Fuel system leak - small leak detected
============5==============
P0093(00)
Raw code: 009300
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Fuel system leak - large leak detected
============6==============
P169F(00)
Raw code: 169F00
ECU: Engine control unit
Status: Test not completed during this operation cycle
============7==============
P1531(96)
Raw code: 153196
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid Test - Accelerator Pedal Movement
Ford: Invalid Test - Accelerator Pedal Movement
============8==============
P0219(00)
Raw code: 021900
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Engine over speed condition
Ford: Engine Overspeed Condition
============9==============
P0605(48)
Raw code: 060548
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Engine control module (ECM) - ROM error
Ford: Powertrain Control Module ROM Test Error
============10==============
P1774(02)
Raw code: 177402
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
============11==============
P1643(64)
Raw code: 164364
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Fuel Pump Monitor Circuit Low Input
Ford: Fuel Pump Monitor Circuit Low Input
============12==============
P1774(64)
Raw code: 177464
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
============13==============
U0404(64)
Raw code: C40464
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid data received - gear shift module
============14==============
P061C(64)
Raw code: 061C64
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Engine control module (ECM), engine rpm - performance problem
============15==============
P1304(00)
Raw code: 130400
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: EGR Calibration High
Ford: EGR Calibration High
============16==============
P1304(91)
Raw code: 130491
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: EGR Calibration High
Ford: EGR Calibration High
============17==============
P1304(85)
Raw code: 130485
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: EGR Calibration High
Ford: EGR Calibration High
============18==============
P2002(00)
Raw code: 200200
ECU: Engine control unit
Status: Test not completed during this operation cycle
OBDII: Particulate trap, bank 1 - efficiency below threshold
============19==============
P1936(31)
Raw code: 193631
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
============20==============
P164D(00)
Raw code: 164D00
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
Ford: ALL WHEEL DRIVE ID BLOCK CORRUPTED, NOT PROGRAMMED
============21==============
U0418(00)
Raw code: C41800
ECU: Engine control unit
Status: Test failed, Test failed (current drive cycle), Test not completed during this operation cycle
OBDII: Invalid data received - brake system control module
============22==============
U0426(00)
Raw code: C42600
ECU: Engine control unit
Status: Test not completed since last DTC clear, Test not completed during this operation cycle
OBDII: Invalid data received - immobilizer control module
***************************
